BOBST AUTOPLATINE SP 102 - BMA
Automatic Die Cutting Machine
#24530
Machine CV Download the offer as PDF
In some way, the machines in our offer are like human job applicants. Some machines are almost new, like a freshly graduated person, while others already have many years of work experience behind themselves. Some machines are more suitable for one kind of activity, whereas others are more suitable for another kind of activity. But, what all the machines have in common is that, from various reasons, all of them are at the moment freed from their last services and are searching for the possibility of a new employment. So, through the CV of every particular machine, meet all the information we were able to get on them.
Basic information
- Manufacturer: Bobst Group, Lauzane, Switzerland
- Production Year: 1999
- Max. Size/Width: 680x1010 mm (26.8"x39.8")
More Details
- diameter of foil reels
- max. 250 mm
- width of foils 15 – 1010 mm
- number of foil driveshafts: 3
- number of different advances per drive shaft: 3
- possible advance repetitions: 99
- minimum advance: 1 mm
- maximum advance (depends on the version of MSS software)
- 680 mm -> 2.01 <-
- 720 mm -> 3.01 <-
- temperature adjustment range 50 – 160°C
- note: Maximum advance is guaranteed up to 5,000 sheets/h
- max. 7500 sheets
- minimum pressure of compressed air ductwork system: 6 bar
- total heating power: 11 kW
- board quality processable:
- paper
- solid board
- corrugated cardboard "E" and "B"
- min. 90 g/m2
- max. 2000 g/m2
- max. 4 mm
- sheet sizes:
- min. 350 x 400 mm
- max. 720 x 1020 mm
- cutting sizes:
- with from trim
- without from trim
- max. 705 x 1020 mm
- max. 720 x 1020 mm
- cutting force
- max. 2,5 MN (250 t)
- hourly rate (depending on cardboard and type of job feature)
- max. 7500 sheets
- motor output
- 13 kW
- connected load
- 30 kVA
- foil baling press
Condition of the Machine
- Very good condition, well maintained, worn out according to its age.
- Not in daily production but can be seen running at your request.
- Availability: immediately
- Sale Reason: production reduction
- Spare parts: replacement frames
- Found Damages: for the drive converter the communication card is not working - repair approx 15 000 EUR
-
Disclaimer:
The Condition of the Machine assessment presented in this CV was either obtained from the last machine operator or is based on an inspection performed by our employee, just to provide you with as much information as possible.
For more certainty we recommend your own check or an assessment of an independent mechanic. We cannot provide you with any machine guarantee.
